Automatic Toys inserting/dropping unit.
Introduction:
Automatic Toys inserting/Dropping unite , designed to solve common challenges in production such as high labor costs, inconsistent output, and hygiene concerns.
Key Features & Benefits:
- Synchronize with the pouch filler.
- Drop 1 toy (or capsule) per pouch.
- Work with counting sensors to avoid double drops.
| Specifications | Parameter | |
|---|---|---|
| Equipment Model | M300 | |
| Delta Parameter | 600mm | |
| External Dimensions | 788mm*495mm*872mm | |
| Loading Capacity | 1.0KG | |
| Flexible Feeder | 305mm*226mm | |
| Hopper Feeder Capacity | 3L | |
| Upper CCD | 1200W | |
| Lower CCD | 500W | |
| Control System | FDR visual feed control system 3.0 | |
| Precision | Standard: 0.15mm Flying shot: 0.05mm | |
| Minimum Grab Range | 0.5mm*0.03mm | |
| Minimum Grab Range | 0.5mm*0.03mm | |
| Speed | 2500-3500PCS/H | |
| Scope of Work | 350mm*250mm | |
| Power Supply Voltage | 220V/50HZ | |
| Air Pressure | 0.5-0.7Mpa | |
| Weight/Power | 80KG/2KW | |
